Installation

2-1

C

HAPTER

2

Installation

Contact Reliance if the drive installation must be in compliance with the European
Community Electromagnetic Compatibility Standards.

The AutoMax Network option board installation procedure differs depending on the
drive type. Use table 2.1 to locate the appropriate procedure for your drive.

Table 2.1 – Locating the Appropriate Installation Procedure

Rating

GV3000/SE Model Number

Use the Procedure in Section …

1 HP

1V21xx

1V24xx

2.4

1 HP

1V41xx

1V44xx

2.2

2 HP

2V21xx

2V24xx

2.4

2 HP

2V41xx

2V44xx

2.2

3 HP

3V21xx

3V24xx

2.4

3 HP

3V41xx

3V44xx

2.2

5 HP

5V21xx

5V24xx

2.4

5 HP

5V41xx

5V44xx

2.2

7.5 HP

7V21xx

7V22xx

2.4

7.5 HP

7V41xx

7V42xx

2.3

10 HP

10V21xx

10V22xx

2.4

10 HP

10V41xx

10V42xx

2.3

15 HP

15V21xx

15V22xx

2.4

15 HP

15V41xx

15V42xx

2.6

20 HP

20V21xx

20V22xx

2.4

20 HP

20V41xx

20V42xx

2.6

25 HP

25G41xx
25G42xx

25V41xx
25V42xx

2.6

30 HP

30V20xx

2.5

30 HP

30V41xx

30V42xx

2.6

40 HP

40V20xx

2.5

40 HP

40V41xx

40V42xx

2.6
