1-2 AutoMax Network Communication Option Board for the GV3000/SE AC Drive
• GV3000/SE 230 VAC 30-100 HP General Purpose (Volts/Hertz) and Vector Duty
Drive Software Start-Up and Reference Manual (D2-3416)
• GV3000/SE AC Drive Hardware Reference, Installation, and Troubleshooting
30-100 HP @ 230 VAC (D2-3417)
• GV3000/SE AC General Purpose (Volts/Hertz) and Vector Duty Bookshelf Drive
Software Start-Up and Reference Manual (D2-3426)
• GV3000/SE AC Bookshelf Power Modules Hardware Reference, Installation, and
Troubleshooting (D2-3427)
• Network Communications Module (J2-3001)
• ReSource AutoMax Programming Executive instruction manual
• Control and Configuration Software (CS3000) instruction manual (D2-3348)
1.3 Related Hardware and Software
When the Network Option board is installed in a GV3000/SE drive, the drive can be
used with the hardware and software listed in table 1.1.
Table 1.1 – Hardware and Software Used with AutoMax Network Option Board (Purchased Separately)
Option Name Model Number Description
75 Ohm Terminating Load 45C71 A terminating load is required at both ends of an
AutoMax network coaxial cable system.
AutoMax Processor 57C430A
55C431
57C435
AutoMax Programming
Executive Various Includes the tools required for programming in
Enhanced Basic, Control Block, and Ladder
Logic/PC languages.
Communications Passive Tap 57C380 Required at each network drop for connection to
coaxial cabling.
Drive Control and
Configuration Software 2CS3000 Windows-based software that allows you to
connect any personal computer running Microsoft
Windows version 3.1 or later to a GV3000/SE
drive. Allows you to create, store, upload, and
download drive configurations.
Network Communications
Module 57C404
57C404A
57C404B
The master drop (and all AutoMax rack slave
drops) on the AutoMax network must contain a
Network Communications module. The Network
Option board emulates the functions of the
Network Communications Module for the
GV3000/SE drive.
ReSource™ Interface Cable 61C127 Cable that connects a personal computer to the
AutoMax Processor module
