Rockwell Automation GV3000/SE AC Drive AutoMax Network Communication Board, M/N 2AX3000 User Manual
Page 36
Installation
2-27
Step 3.4 Use a magnetic screwdriver to remove the four screws and lock washers
that fasten the keypad bracket to the hinged mounting panel. Hold the
keypad bracket as you remove the screws.
Figure 2.15 – 100 to 150 HP GV3000/SE Drive Components and Locations
Keypad
Regulator Board
Power Module
Interface Board
Regulator Panel
DC bus measuring
points are behind the
Regulator Panel on the
Power Module Interface
board.
Power Module
Interface Board
Power Module Interface Board
(–) (+)
Fuses
DC Bus Measuring Points
