Chapter 3
Programming and Parameters
AppView Parameter Groups
PowerFlex 520-series drives include various AppView™ parameter groups that
groups certain parameters together for quick and easy access based on different
types of applications. See
AppView Parameter Groups on page 138
for more
information.
Fault and Diagnostic
Fault 4 Code
F604
Fault 5 Code
F605
Fault 6 Code
F606
Fault 7 Code
F607
Fault 8 Code
F608
Fault 9 Code
F609
Fault10 Code
F610
Fault 1 Time-hr
F611
Fault 2 Time-hr
F612
Fault 3 Time-hr
F613
Fault 4 Time-hr
F614
Fault 5 Time-hr
F615
Fault 6 Time-hr
(1)
F616
Fault 7 Time-hr
(1)
F617
Fault 8 Time-hr
(1)
F618
Fault 9 Time-hr
(1)
F619
Fault10 Time-hr
(1)
F620
Fault 1 Time-min
F621
Fault 2 Time-min
F622
Fault 3 Time-min
F623
Fault 4 Time-min
F624
Fault 5 Time-min
F625
Fault 6 Time-min
(1)
F626
Fault 7 Time-min
(1)
F627
Fault 8 Time-min
(1)
F628
Fault 9 Time-min
(1)
F629
Fault10 Time-min
(1)
F630
Fault 1 Freq
F631
Fault 2 Freq
F632
Fault 3 Freq
F633
Fault 4 Freq
F634
Fault 5 Freq
F635
Fault 6 Freq
(1)
F636
Fault 7 Freq
(1)
F637
Fault 8 Freq
(1)
F638
Fault 9 Freq
(1)
F639
Fault10 Freq
(1)
F640
Fault 1 Current
F641
Fault 2 Current
F642
Fault 3 Current
F643
Fault 4 Current
F644
Fault 5 Current
F645
Fault 6 Current
(1)
F646
Fault 7 Current
(1)
F647
Fault 8 Current
(1)
F648
Fault 9 Current
(1)
F649
Fault10 Current
(1)
F650
Fault 1 BusVolts
F651
Fault 2 BusVolts
F652
Fault 3 BusVolts
F653
Fault 4 BusVolts
F654
Fault 5 BusVolts
F655
Fault 6 BusVolts
(1)
F656
Fault 7 BusVolts
(1)
F657
Fault 8 BusVolts
(1)
F658
Fault 9 BusVolts
(1)
F659
Fault10 BusVolts
(1)
F660
Status @ Fault 1
F661
Status @ Fault 2
F662
Status @ Fault 3
F663
Status @ Fault 4
F664
Status @ Fault 5
F665
Status @ Fault 6
(1)
F666
Status @ Fault 7
(1)
F667
Status @ Fault 8
(1)
F668
Status @ Fault 9
(1)
F669
Status @ Fault10
(1)
F670
Comm Sts - DSI
F681
Comm Sts - Opt
F682
Com Sts-Emb Enet
(1)
F683
EN Addr Src
(1)
F684
EN Rate Act
(1)
F685
DSI I/O Act
F686
HW Addr 1
(1)
F687
HW Addr 2
(1)
F688
HW Addr 3
(1)
F689
HW Addr 4
(1)
F690
HW Addr 5
(1)
F691
HW Addr 6
(1)
F692
EN IP Addr Act 1
(1)
F693
EN IP Addr Act 2
(1)
F694
EN IP Addr Act 3
(1)
F695
EN IP Addr Act 4
(1)
F696
EN Subnet Act 1
(1)
F697
EN Subnet Act 2
(1)
F698
EN Subnet Act 3
(1)
F699
EN Subnet Act 4
(1)
F700
EN Gateway Act 1
(1)
F701
EN Gateway Act 2
(1)
F702
EN Gateway Act 3
(1)
F703
EN Gateway Act 4
(1)
F704
Drv 0 Logic Cmd
F705
Drv 0 Reference
F706
Drv 0 Logic Sts
F707
Drv 0 Feedback
F708
Drv 1 Logic Cmd
F709
Drv 1 Reference
F710
Drv 1 Logic Sts
F711
Drv 1 Feedback
F712
Drv 2 Logic Cmd
F713
Drv 2 Reference
F714
Drv 2 Logic Sts
F715
Drv 2 Feedback
F716
Drv 3 Logic Cmd
F717
Drv 3 Reference
F718
Drv 3 Logic Sts
F719
Drv 3 Feedback
F720
Drv 4 Logic Cmd
F721
Drv 4 Reference
F722
Drv 4 Logic Sts
F723
Drv 4 Feedback
F724
EN Rx Overruns
(1)
F725
EN Rx Packets
(1)
F726
EN Rx Errors
(1)
F727
EN Tx Packets
(1)
F728
EN Tx Errors
(1)
F729
EN Missed IO Pkt
(1)
F730
DSI Errors
F731
(1) Parameter is specific to PowerFlex 525 drives only.
Conveyor
Language
P030
Output Freq
b001
Commanded Freq
b002
Motor NP Volts
P031
Motor NP Hertz
P032
Motor OL Current
P033
Motor NP FLA
P034
Motor NP Poles
P035
Autotune
P040
Accel Time 1
P041
Decel Time 1
P042
Minimum Freq
P043
Maximum Freq
P044
Stop Mode
P045
Start Source 1
P046
Speed Reference1
P047
DigIn TermBlk 02
t062
DigIn TermBlk 03
t063
Opto Out1 Sel
t069
Relay Out1 Sel
t076
Anlg In 0-10V Lo
t091
Anlg In 0-10V Hi
t092
Anlg In4-20mA Lo
t095
Anlg In4-20mA Hi
t096
Anlg In mA Loss
t097
Slip Hz Meter
d375
Preset Freq 0
A410
Jog Frequency
A431
Jog Accel/Decel
A432
S Curve %
A439
Reverse Disable
A544
Mixer
Language
P030
Output Freq
b001
Commanded Freq
b002
Output Current
b003
Motor NP Volts
P031
Motor NP Hertz
P032
Motor OL Current
P033
Motor NP FLA
P034
Motor NP Poles
P035
Autotune
P040
Accel Time 1
P041
Decel Time 1
P042
Minimum Freq
P043
Maximum Freq
P044
Stop Mode
P045
Start Source 1
P046
Speed Reference1
P047
Relay Out1 Sel
t076
Anlg In 0-10V Lo
t091
Anlg In 0-10V Hi
t092
Anlg In4-20mA Lo
t095
Anlg In4-20mA Hi
t096
Anlg In mA Loss
t097
Preset Freq 0
A410
Stall Fault Time
A492
Compressor
Language
P030
Output Freq
b001
Commanded Freq
b002
Motor NP Volts
P031
Motor NP Hertz
P032
Motor OL Current
P033
Motor NP FLA
P034
Motor NP Poles
P035
Autotune
P040
Accel Time 1
P041
Decel Time 1
P042
Minimum Freq
P043
Maximum Freq
P044
Stop Mode
P045
Start Source 1
P046
Speed Reference1
P047
Relay Out1 Sel
t076
Analog Out Sel
t088
Analog Out High
t089
Anlg Out Setpt
t090
Anlg In 0-10V Lo
t091
Anlg In 0-10V Hi
t092
Anlg In4-20mA Lo
t095
Anlg In4-20mA Hi
t096
Anlg In mA Loss
t097
Preset Freq 0
A410
Auto Rstrt Tries
A541
Auto Rstrt Delay
A542
Start At PowerUp
A543
Reverse Disable
A544
Power Loss Mode
A548
Half Bus Enable
A549
