Appendix B
Accessories and Dimensions
PowerFlex 520-Series
Heatsink Fan Kit
Replacement fan for drive power module.
A
25-FAN1-FA
B
25-FAN1-FB
C
25-FAN1-FC
D
25-FAN1-FD
E
25-FAN1-FE
PowerFlex 520-Series EMC
Cores
Replacement EMC cores
A
25-CORE-A
25-CORE-RF-A
B
25-CORE-B
25-CORE-RF-B
C
25-CORE-C
25-CORE-RF-C
D
25-CORE-D
25-CORE-RF-D
E
25-CORE-E
25-CORE-RF-E
Communication Option Kits and Accessories
Item
Description
Catalog No.
Communication Adapters
Embedded communication options for use with the
PowerFlex 520-Series drives:
• DeviceNet™
• Dual Port EtherNet/IP™
• PROFIBUS™ DP-V1
25-COMM-D
25-COMM-E2P
25-COMM-P
Compact I/O Module
Three channel
1769-SM2
Universal Serial Bus™ (USB)
Converter Module
Provides serial communication with DF1 protocol for use with
Connected Components Workbench software. Includes:
• 2 m USB cable (1)
• 20-HIM-H10 cable (1)
• 22-HIM-H10 cable (1)
1203-USB
Serial Converter Module
(RS485 to RS232)
Provides serial communication with DF1 protocol for use with
Connected Components Workbench software. Includes:
• DSI to RS232 serial converter (1)
• 1203-SFC serial cable (1)
• 22-RJ45CBL-C20 cable (1)
22-SCM-232
DSI Cable
2.0 m RJ45 to RJ45 cable, male to male connectors.
22-RJ45CBL-C20
Serial Cable
2.0 m serial cable with a locking low profile connector to
connect to the serial converter and a 9-pin sub-miniature D
female connector to connect to a computer.
1203-SFC
Splitter Cable
RJ45 one to two port splitter cable (Modbus only)
AK-U0-RJ45-SC1
Terminating Resistors
RJ45 120 Ohm resistors (2 pieces)
AK-U0-RJ45-TR1
Terminal Block
RJ45 Two position terminal block (5 pieces)
AK-U0-RJ45-TB2P
Connected Components
Workbench Software
(Download or DVD-ROM)
Windows-based software packages for programming and
configuring Allen-Bradley drives and other Rockwell
Automation products.
Compatibility:
Windows XP, Windows Vista and Windows 7
Other Parts
Item
Description
Frame
Size
Catalog No.
