13-84 EQP LOGIC EDITOR
Version 6.0
Item 152 - Activate Reset
Setting this control item instructs the controller to send a reset command to the field device.
Item 153 - Start Manual Oi Test
Setting this control item instructs the controller to send a start manual Oi test command to the field device.
Item 154 - Release
Setting this control item instructs the controller to sendrelease command to the ARM module. This will cause the
output to activate.
Item 155 - Isolate
Setting this control item instructs the controller to send isolate command to the field device. This will cause the
output to go to the isolate mode.
Item 156 - Select UV or IR
Changing this control item instructs the UVIR flame detector to send the UV or the IR signal.
Value PV Value
1 UV Signal
2 IR Signal
Item 157 - Activate Continuous
Setting this control item instructs the field device output to turn on in the continuous mode.
Item 158 - Activate 60 bpm
Setting this control item instructs the field device output to turn on in the 60 bpm mode.
Item 159 - Activate 120 bpm
Setting this control item instructs the field device output to turn on in the 120 bpm mode.
Item 160 - Activate Temporal
Setting this control item instructs the field device output to turn on in the temporal mode.
Item 161 - Request Extended Status
Setting this control item instructs the controller to retrieve the extended status information from the fielded
device.
Item 162 - Activate Timed
Setting this control item instructs the controller to activate an output in the timed mode.
Item 163 - Activate Fire Alarm
Setting this control item in the controller activates the fire alarm output. When this bit is set in a field device the
output signals the temporal fire alarm pattern.
Item 164 - Activate Trouble Output
Setting this control item in the controller activates the trouble output. When this bit is set in a field device the
output signals the trouble pattern.
DEVICE ITEM NUMBER DESCRIPTIONS
