13-67 EQP LOGIC EDITOR
Version 6.0 DEVICE ITEM NUMBER DESCRIPTIONS
Item 7 - Device Code
Each device type has a unique code associated with it. Controller to PC configuration software use “Device
Codes” to identify device types. The Controller to field device interface uses “LON Type Code” for backward
compatibility with older devices.
Device Code Device LON Type Code
1 EQ2200DCU 95
2 EQ2200IDC 91
3 EQ2200UV 92
4 EQ2500SAM 93
5 EQ2500ARM 94
6 EQ2200UV/IR 96
7 EQ2100PSM 97
8 EQ3700DCIO 110
9 EQ3720RM 111
10 EQ3710AIM 112
11 8 Point Pulsed Input Module 113
12 PIRECL (Eclipse) 98
13 X3301 99
14 X2200 (UV) 114
15 X9800 (IR) 115
16 X5200 (UV/IR) 116
17 EQ3740IPM 117
18 EQ3730EDIO 118
19 X3302 119
20 EQ3750ASH 120
21 X3301A 121
22 EDIO-SIL 122
23 X3301-SIL 123
24 Eclipse-SIL 124
25 Open Path 125
100 EQ3000 (Premier Controller) 200
500 EQP Controller Relay
501 EQP Controller Digital Inputs
502 User Event
Item 8 - Tag Name
User defined 20 character null terminated string.
Item 9 - Descriptor
User defined 42 character null terminated string.
Item 10 - Update Rate
The frequency of field device status transmission is adjusted with this variable. The allowable range is from 1,000
to 10,000 ms.
