Electrical System
9.50
G10-55A & G12-55A AccuPlace
RT STAB FDBK:
XXXXmA
Current feedback measured on Right Stabilizer
Valve Return.
REAR AXLE OUT1:
ON/OFF
Displays UGM Rear Oscillating Axle Lock output
state for Coil 1.
REAR AXLE OUT2:
ON/OFF
Displays UGM Rear Oscillating Axle Lock output
state for Coil 2.
CIRC OUTPUT:
ON/OFF
Displays the UGM Circulation Valve output state.
CAB JOYSTICK:
JOYSTICK X:
±XXX%
Displays position in percentage for this axis.
X NEUTRAL:
NEUTRAL, NOT
NEUTRAL, ERROR
Indicates whether joystick is in neutral position for
this axis.
JOYSTICK Y:
±XXX%
Displays position in percentage for this axis.
Y NEUTRAL:
NEUTRAL, NOT
NEUTRAL, ERROR
Indicates whether joystick is in neutral position for
this axis.
JOYSTICK AR:
±XXX%
Displays position in percentage for the analog
rocker.
AR NEUTRAL:
NEUTRAL, NOT
NEUTRAL, ERROR
Indicates whether analog rocker is in neutral
position.
JOYSTICK S1:
ON/OFF
Displays status of S1 pushbutton.
MINI JOYSTICKS: SWAY JOY CMD:
±XXX%
Displays position in percentage for this axis;
positive is lower voltages and negative is higher
voltages.
SWAY JOY SIGNAL:
X.XV
Provides voltage signal output for joystick.
SWAY NEUTRAL SW: NEUTRAL/OUT OF
NEUTRAL
Indicates whether joystick switches designate out-
of-neutral position.
AUX JOY CMD:
±XXX%
Displays position in percentage for this axis;
positive is lower voltages and negative is higher
voltages.
AUX JOY SIGNAL:
X.XV
Provides voltage signal output for joystick.
AUX NEUTRAL SW:
NEUTRAL/OUT OF
NEUTRAL
Indicates whether joystick switches designate out-
of-neutral position.
LT STAB JOY CMD:
±XXX%
Displays position in percentage for this axis;
positive is lower voltages and negative is higher
voltages.
LT STAB SIGNAL:
X.XV
Provides voltage signal output for joystick.
LT STAB NEUT SW:
NEUTRAL/OUT OF
NEUTRAL
Indicates whether joystick switches designate out-
of-neutral position.
Diagnostics
Submenu
(Displayed on
Analyzer 1
st
Line)
Parameter
(Displayed on
Analyzer 1
st
Line)
Parameter Value
(Displayed on
Analyzer 2
nd
Line)
Description
