9.43 G10-55A & G12-55A AccuPlace
Electrical System
High End Fault Voltage (5V supply)
“FAULT HIGH”
4.75V 4.40-4.90V
LEFT STABILIZER
JOYSTICK
Low Center Deadband Voltage (5V supply)
“DEADBAND LOW”
2.3V 1.90-2.50V
High Center Deadband Voltage (5V supply)
“DEADBAND HIGH”
2.7V 2.20-3.00V
Low End Voltage (min command; 5V supply)
“MIN VOLTAGE”
0.5V 0.30-0.70V
High End Voltage
(max command; 5V supply)
“MAX VOLTAGE”
4.4V 4.00-4.60V
Low End Fault Voltage (5V supply)
“FAULT LOW”
0.25V 0.10-0.40V
High End Fault Voltage (5V supply)
“FAULT HIGH”
4.75V 4.40-4.90V
RIGHT STABILIZER
JOYSTICK
Low Center Deadband Voltage (5V supply)
“DEADBAND LOW”
2.3V 1.90-2.50V
High Center Deadband Voltage (5V supply)
“DEADBAND HIGH”
2.7V 2.20-3.00V
Low End Voltage (min command; 5V supply)
“MIN VOLTAGE”
0.5V 0.30-0.70V
High End Voltage
(max command; 5V supply)
“MAX VOLTAGE”
4.4V 4.00-4.60V
Low End Fault Voltage (5V supply)
“FAULT LOW”
0.25V 0.10-0.40V
High End Fault Voltage (5V supply)
“FAULT HIGH”
4.75V 4.40-4.90V
BOOM Acceleration up
“LIFT UP ACCEL”
0.1000 kph 0.001-0.2 kph
Deceleration up
“LIFT UP DECEL”
0.0500 kph 0.006-0.2 kph
Acceleration down
“LIFT DN ACCEL”
0.0200 kph 0.001-0.2 kph
Function Personality Default Setting Adjustment Range
