90

© 2014 AEM Performance Electronics

Infinity User Manual

Has Secondary Injectors
If secondary injectors will be used, select this check box. A new fuel type menu is now visible
labeled Fuel Type (Secondary Injectors).

See

Staged Injection

for additional tuning information.

Note: If secondary injectors are being used, the option Has Secondary Injectors must be
selected and the table must be filled out indicating any injector number greater than the number
of engine cylinders as secondary. These selections must be made before restarting the ECU
and closing the form; otherwise an error will occur. See image below for a typical 6 cylinder
engine setup with 6 additional injectors classified as secondary. Note also the option to select a
different fuel type for primary and secondary.

262
