knocking but still below their maximum value in response to audible pinging or slight
detonation observed in the power trace of a dyno plot.
Integrator (smoothing) Time
Units: uS
Description: This can be adjusted to dampen the response to background noise, but be
careful not to increase this time to a point that the filter is too slow in responding to actual
knock activity.
Sensor Assignment and Window Angle
The table shown below assigns a knock sensor and a window range to each specific cylinder.
