Infinity Pin
Hardware Ref.
Hardware Specification
Notes
the 1D lookup table 'ShiftSwitch' for setup. Also
assignable to multiple functions. See Setup
Wizard for details.
C1-75
Analog_In_10
12 bit A/D, 100K pullup to 5V
0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced to
+12V as this can permanently damage the ECU.
See the Setup Wizard Barometric Pressure page
for setup and calibration. Monitor the
BaroPress [kPa] channel.
C1-76
Injector 3_Out
Saturated (P/N 30-7108) or peak and
hold, 3A max continuous (P/N 30-7106)
Injector 3
C1-77
Injector 2_Out
Saturated (P/N 30-7108) or peak and
hold, 3A max continuous (P/N 30-7106)
Injector 2
C1-78
Injector 1_Out
Saturated (P/N 30-7108) or peak and
hold, 3A max continuous (P/N 30-7106)
Injector 1
C1-79
Stepper_2A_Out
Automotive, Programmable Stepper
Driver, up to 28V and ±1.4A
Be sure that each internal coil of the stepper
motor are properly paired with the 1A/1B and
2A/2B ECU outputs. Supports Bi-Polar stepper
motors only.
C1-80
Stepper_1A_Out
Automotive, Programmable Stepper
Driver, up to 28V and ±1.4A
Be sure that each internal coil of the stepper
motor are properly paired with the 1A/1B and
2A/2B ECU outputs. Supports Bi-Polar stepper
motors only.
