AEM 30-71XX Infinity Stand-Alone Programmable Engine Mangement System Full Manual User Manual
Page 275
Tuning Guide
269
© 2014 AEM Performance Electronics
UEGO Mode A, B, C:
Shows operating mode of UEGO controller, if using multiple controller and there are duplicate
numbers, please refer to 4ch UEGO controller manual to adjust mode to avoid overlapping and
properly monitor all cylinders.
UEGO Sensor Heating A, B, C:
Displays values representing sensor heating per cylinder from associated mode. (i.e., UEGO
Sensor Heating A, will show a value of 15 for cylinders 1, 2, 3, 4 if controller is set to mode 1 and
all sensors are ready.)
