Infinity User Manual

Charge Out Pressure Setup:
Input selector for Charge Out Pressure. Note: Only one option may be available depending on
which pakgrp is loaded.

CP Volts Min:
This sets the minimum voltage capable from a properly working sensor. Check the manufacturer
specifications for more information. Min value = 0, Max value = 5. CP Volts Min must be < CP
Volts Max. User entries that do not meet this criteria are not allowed.

CP Volts Max:
This sets the minimum voltage capable from a properly working sensor. Check the manufacturer
specifications for more information. Min value = 0, Max value = 5. CP Volts Min must be < CP
Volts Max. User entries that do not meet this criteria are not allowed.

CP Cal Min:
This sets the minimum pressure capable, in kPa, from a properly working sensor. Check the
manufacturer specifications for more information. Min value = 0, Max value = 1300. CP Cal Max
must be > CP Cal Min. User entries that do not meet this criteria are not allowed.

CP Cal Max:
This sets the minimum pressure capable, in kPa, from a properly working sensor. Check the
manufacturer specifications for more information. Min value = 0, Max value = 1300. CP Cal Max
must be > CP Cal Min. User entries that do not meet this criteria are not allowed.
