Infinity Pin

Hardware Ref.

Hardware Specification

Notes

Connect directly to battery ground

C1-47

+12V_Relay_Control_Out

0.7A max ground sink for external relay
control

Will activate at key on and at key off according
to the configuration settings.

C1-48

+12V_SW_In

10K pulldown

Full time battery power must be available at C1-
10 before this input is triggered.

C1-49

+5V_Out_1

Regulated, fused +5V supply for sensor
power

Analog sensor power

C1-50

+5V_Out_1

Regulated, fused +5V supply for sensor
power

Analog sensor power

C1-51

Analog_In_7

12 bit A/D, 100K pullup to 5V

0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced to
+12V as this can permanently damage the ECU.
See the Setup Wizard Set Throttle Range page for
automatic min/max calibration. Monitor the
Throttle [%] channel. Also DB1_TPSA [%] for DBW
applications.

C1-52

Analog_In_8

12 bit A/D, 100K pullup to 5V

0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced to
+12V as this can permanently damage the ECU.
See the Setup Wizard Set Manifold Pressure
page for setup and calibration. Monitor the MAP
[kPa] channel.

C1-53

Analog_In_9

12 bit A/D, 100K pullup to 5V

0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced to
+12V as this can permanently damage the ECU.
See the Setup Wizard Fuel Pressure page for
setup and calibration. Monitor the
FuelPressure [psig] channel.

C1-54

VR+_In_2

Differential Variable Reluctance Zero
Cross Detection

See Non Driven Wheel Speed Calibration in the
Setup Wizard Vehicle Speed page.

C1-55

VR-_In_2

C1-56

VR-_In_3

Differential Variable Reluctance Zero
Cross Detection

See Driven Wheel Speed Calibration in the Setup
Wizard Vehicle Speed page.

C1-57

VR+_In_3

C1-58

HighsideSwitch_0_Out

2.6A max, High Side Solid State Relay

See Setup Wizard page 'HighSide Assigment
Tables' for configuration options. See 2D lookup
table 'HS0_Table' for activation settings.
See
Setup Wizard page 'VTEC' for default activation
criteria.

C1-59

Stepper_1B_Out

Automotive, Programmable Stepper
Driver, up to 28V and ±1.4A

Be sure that each internal coil of the stepper
motor are properly paired with the 1A/1B and
2A/2B ECU outputs. Supports Bi-Polar stepper
motors only.

C1-60

Stepper_2B_Out

Automotive, Programmable Stepper
Driver, up to 28V and ±1.4A

Be sure that each internal coil of the stepper
motor are properly paired with the 1A/1B and
2A/2B ECU outputs. Supports Bi-Polar stepper
motors only.
