Tuning Guide

207

© 2014 AEM Performance Electronics

Nitrous Trims: Advanced Setup:

Nitrous Output Delay:
Units: Time

Nitrous Trim Delay:
Units: Time

Nitrous Trim Decay Time:
Units: Time

Associated Tables:

N2O_Switch:
Units: Off = 0, On = 1
This table sets digital input condition to arm Nitrous, Set all cells to 1 if not using a digital input to
arm.

N2O_Fuel:
Units: Pressure vs Engine Speed vs Fuel % (decimal)
Range: Min value = -1.00, Max value = 1.55
This map allows a percentage of additional fuel to be added or subtracted from the base map
when the nitrous options become active. This map allows adjustment over engine speed and
manifold pressure.

N2O_Ign [deg]:
Units: Pressure vs Engine Speed vs Degrees
Range: Min value = -43.75, Max value = 20.00
This map allows ignition timing to be advanced or retarded against the base ignition map when
the nitrous control is active. This map is adjustable over engine speed and manifold pressure.
