Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-46 61179641AL4-5B
The Inband OAM Loopback Test menu fields are shown in Table 5-27 .
Table 5-27. Inband OAM Loopback Test Menu Fields
Field Description
Port This field displays the physical port.
VPI This field displays the VPI for the circuit.
VCI This field displays the VCI for the circuit.
Tx Loopback Request This field displays the total number of transmitted loopback
requests.
Rx Loopback Request This field displays the total number of received loopback
requests.
Tx Loopback Response This field displays the total number of transmitted loopback
responses.
Rx Loopback Response This field displays the total number of received loopback
responses.
Loopback Passed This field displays the total number of loopback request that
passed.
Loopback Failed This field displays the total number of loopback request that
failed.
Rx OAM Cells This field displays the total number of received OAM cells.
AIS State This field indicates if the Endpoint is in AIS state (True) or not
(False).
RDI State This field indicates if the Endpoint is in the RDI state (True) or
not (False).
