Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
3-22
61179641AL4-5B
10. From the T1 Provisioning menu, configure the
Type
,
Framing
,
Line Code
, and
Line Build Out
setting to match the settings of the T1s provided. Press
N
to access the next T1 to
configure and continue this process until all the T1s are properly configured.
11. From the T1 Provisioning menu, press
E
SC
to return to the T1 Main Menu.
12. From the T1 Main Menu, select T1 Status, and press
E
NTER
.
13. From the T1 Status menu, confirm that the T1s do not have active alarms.
NOTE
If the T1s have active alarms, this is an indication of a network feed
issue.
14. From the T1 Status menu, press
E
SC
until the Network Port menu displays.
15. From the Network Port menu, select
IMA
and press
E
NTER
.
16. From the IMA Main Menu, select
Provisioning
, and press
E
NTER
.
17. From the IMA Provisioning menu, select
IMA Facility
, and press
E
NTER
.
18. From the IMA Facility Provisioning for # 1 menu, select
Facility Operation Mode
, and press
E
NTER
.
19. From the Operation Mode for Facility for # 1 menu, provision the facilities as appropriate.
For more information, refer to
“Operation Mode for Facility Menu”
The default settings assign the 8 facilities to the IMA Group.
20. From the Operation Mode for Facility for # 1 menu, press
E
SC
until the IMA Provisioning
menu displays.
21. From the IMA Provisioning menu, select
IMA Group
, and press
E
NTER
.
22. From the IMA Group Provisioning menu, select
Group Operation Mode
, and press
E
NTER
.
23. From the Group Operation Mode menu, select
In Service
, and press
E
NTER
.
24. Press
E
SC
until the Main menu displays.
25. From the Main menu, select
System Management
, and press
E
NTER
26. From the System Management menu, select
IP Address
, and press
E
NTER
.
27. From the Mode Selection and Current IP Settings menu, verify that the Mode is set to
Static
.
28. From the Mode Selection and Current IP Settings menu, select
Configure IP
, and press
E
NTER
.
29. From the Status IP Settings - for IP over ATM menu, configure the following fields:
• IP Address
• Subnet Mask
• VPI/VCI
• Default Gateway
