Menu Descriptions
61179641AL4-5B 5-109
E1 Performance Monitoring Status Screen
E1 Performance Monitoring Status
Main Menu \ Network Port \ E1 Main Menu \ E1 PM Main Menu \E1 Performance Monitoring Status\
The E1 Performance Monitoring Status screen (see Figure 5-73 ) displays performance
monitoring in 24-hour and 15-minute increments for the current port selected.
NOTE
To display the Abbreviations screen, press “ ? ”.
Figure 5-73. E1 Performance Monitoring Status Screen
The E1 Performance Monitoring Status screen codes are shown in Table 5-75 .
Table 5-75. E1 Performance Monitoring Status Screen Codes
Code Definition Description
UAS-P Unavailable Seconds This code indicates seconds with a loss of signal or
synchronization on the path.
ES-P Errored Seconds This code indicates seconds with either a bipolar
violation or a CRC-6 error on the path.
SES-P Severely Errored Seconds This code indicates seconds with 1544 bipolar violations
or 320 CRC-6 errors on the path.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
E1 Performance Monitoring Status - E1 Port:1
UAS-P ES-P SES-P CV-P CV-L ES-L
24 Hr - Current 25279 0 0 0 0 0
--/-- - - - - - -
15 Min - Current 312 0 0 0 0 0
08:45 900 0 0 0 0 0
08:30 900 0 0 0 0 0
08:15 900 0 0 0 0 0
08:00 900 0 0 0 0 0
07:45 900 0 0 0 0 0
07:30 900 0 0 0 0 0
07:15 900 0 0 0 0 0
07:00 900 0 0 0 0 0
B - Backward(2hrs/15min PM) F - Forward(2hrs/15min PM)
S - Select Port P - Previous Port N - Next Port C - Clear PM Stats
'?' - System Help Screen
