Section 5
User Interface
INTRODUCTION
This section provides detailed information on the following:
•
•
“Logging on to the Total Access 1248”
•
•
•
•
SYSTEM MANAGEMENT
Total Access 1248 system management and provisioning is facilitated by a series of intuitive
menus that are accessible on a computer screen. The Total Access 1248 provides two methods
for management access:
•
•
Craft Interface
Connection to the Total Access 1248 system menus can be made through the DB-9 connector,
labeled
CRAFT,
on the front of the Total Access 1248 system. A DB-9 straight cable is required.
The craft port is located behind the front panel cover (see
) of the Total Access 1248.
Figure 5-1. Craft Port Location
PORTS 1-24
ALARM
CRAFT
