IMA All Facilities Provisioning Screen
IMA All Facilities Provisioning
Main Menu \ Network Port \ IMA Main Menu \ IMA Provisioning \ IMA Facility Provisioning \IMA All Facilities Provisioning\
The IMA All Facilities Provisioning screen (see Figure 5-80 ) provides a summary of all the IMA
facilities.
Figure 5-80. IMA All Facilities Provisioning Screen
The IMA All Facilities Provisioning screen fields are shown in Table 5-82 .
Table 5-82. IMA All Facilities Provisioning Screen Fields
Field Description
Operation Mode This field displays the operation mode for the IMA facility. For
more information, refer to
“Operation Mode for Facility Menu”
on page 5-118.
RX Group This field displays the IMA Group ID being received from the Far
End for the facility.
RX Link ID This field displays the Link ID received from the Far End for the
facility.
RX ATM Address This field displays the receive ATM address. This field is
applicable in Pass Thru mode only.
TX Group This field displays the IMA Group transmit ID.
TX Link ID This field displays the Link ID transmitting to Far End for the
facility.
TX ATM Address This field displays the transmit ATM address. This field is
applicable in Pass Thru mode only.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
IMA All Facilities Provisioning
Fac1 Fac2 Fac3 Fac4 Fac5 Fac6 Fac7 Fac8
Operation Mode IMA Grp IMA Grp IMA Grp IMA Grp IMA Grp IMA Grp IMA Grp IMA Grp
RX Group 1 1 1 1 1 1 1 1
RX Link ID 0 1 2 3 4 5 6 7
RX ATM Address N/A N/A N/A N/A N/A N/A N/A N/A
TX Group 1 1 1 1 1 1 1 1
TX Link ID 0 1 2 3 4 5 6 7
TX ATM Address N/A N/A N/A N/A N/A N/A N/A N/A
'?' - System Help Screen
