Menu Descriptions
61179641AL4-5B
5-131
IMA Loopback Menu
IMA Loopback
\
\
The IMA Loopback menu (see
) is used to initiate loopbacks for testing the IMA
group. Each IMA Loopback menu option can be enabled or disabled.
Figure 5-89. IMA Loopback Menu
The IMA Loopback menu options are shown in
.
Table 5-91. IMA Loopback Menu Options
Option
Description
Function
1
Data Lpbk Towards Network
This option when enabled is used to perform a data
loopback toward the network.
2
ATM Lpbk Towards Network
This option when enabled is used to perform an ATM
loopback toward the network.
3
ATM Lpbk Towards Customer
This option when enabled is used to perform an ATM
loopback toward the customer.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
IMA Loopback Menu
1. Data Lpbk Towards Network DISABLED
2. ATM Lpbk Towards Network DISABLED
3. ATM Lpbk Towards Customer DISABLED
Selection :
'?' - System Help Screen
