Modify an Existing PVC/PVP Screen
Modify Existing PVC/PVP
Main Menu \ ATM Circuit Management \ PVC/PVP Management \Modify Existing PVC/PVP\
The Modify an Existing PVC/PVP screen (see Figure 5-14 ) is used to modify existing PVC/
PVPs.
Figure 5-14. Modify an Existing PVC/PVP Screen
The Modify an Existing PVC/PVP screen fields are shown in Table 5-9 .
Table 5-9. Modify an Existing PVC/PVP Screen Fields
Field Description
Endpoint 1 Port This field displays the network port.
Endpoint 1 VPI This field displays the Virtual Path Identifier for the ATM port
from the Network. Valid values range from 0 to 4095.
Endpoint 1 VCI This field displays the Virtual Channel Identifier for the ATM
port from the network. Valid values range from 0 to 65535.
Endpoint 2 Port This field displays the ATM port that is being created. Valid
values range from 1 to 48.
Endpoint 2 VPI This field displays the Virtual Path Identifier for the ATM port.
Valid values range from 0 to 4095.
Endpoint 2 VCI This field displays the Virtual Channel Identifier for the ATM.
Valid values range from 0 to 65535.
Modify an Existing PVC/PVP
Endpoint 1 (Net --> Cust) Endpoint 2 (Net <-- Cust)
Port VPI VCI Port VPI VCI
Netw 35 1000 1 0 35
____________________________________________________________
Service Pkt Discard PCR
UBR Enabled Best Effort
Circuit ID
N/A
____________________________________________________________
When finished, place cursor here to select action:
Modify existing circuit and return to PVC/PVP Management
NOTE: No changes will take effect until an action is selected and executed.
To Select an action, place the cursor over the Action option and press the
Space Bar. To execute the action, press Enter.
Enter a VPI value between 0 and 4095.
