Menu Descriptions
61179641AL4-5B 5-151
Cabinet Mode for Port: # Menu
Cabinet Mode for Port: #
Main Menu \ DSL Menus \ DSL Provisioning \ Port Provisioning \Cabinet Mode for Port: #\
The Cabinet Mode option on the Port Provisioning Menu displays the Cabinet Mode for Port: #
menu (see Figure 5-102 ). The # represents the value displayed for the Select Port option. This
option permits the ADSL2+ line to only use downstream tones beginning at Tone 110, 130,
and 250. The Cabinet Mode should only be enabled when using ADSL2+ capable modems.
Figure 5-102. Cabinet Mode for Port # Menu
The Cabinet Mode for Port: # menu options are shown in Table 5-107 .
Table 5-106. Hamband Mask for Port: # Menu Options
Option Description Function
1 Enabled This option enables hamband masking.
2 Disabled This option disables hamband masking.
Table 5-107. Cabinet Mode for Port: # Menu Options
Option Description Function
1 Disabled This option disables Cabinet Mode.
2 Enabled - Tone 250 This option enables the downstream at Tone 250.
3 Enabled - Tone 110 This option enables the downstream at Tone 110.
4 Enabled - Tone 130 This option enables the downstream at Tone 130.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
Cabinet Mode For Port:1
1. Disabled
2. Enabled - (Tone 250)
3. Enabled - (Tone 110)
4. Enabled - (Tone 130)
Selection :
NOTE: Cabinet Mode is only available on
ports provisioned as ADSL2+ or Multimode.
'?' - System Help Screen
