Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-42 61179641AL4-5B
ATM Port Cell Count Summary Screen
ATM Port Cell Count Summary
Main Menu \ ATM Circuit Management \ ATM Performance Monitoring Mode \ATM Port Cell Count Summary\
The ATM Port Cell Count Summary screen (see Figure 5-25 ) displays a summary of cell counts
for all ports simultaneously.
Figure 5-25. ATM Port Cell Count Summary Screen
The ATM Port Cell Count Summary screen fields are shown in Table 5-23 .
Table 5-23. ATM Port Cell Count Summary Screen Fields
Field Description
Port This field displays the port number for the cell count summary.
Tx This field displays the number of cells transmitted to the
network.
Rx This field displays the number of cells received from the
network and transmitted to the customer.
Disc. This field displays the number of discarded cells.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
ATM Port Cell Count Summary
Port Tx Rx Disc. Port Tx Rx Disc.
1 0 0 0 13 0 0 0
2 0 0 0 14 0 0 0
3 0 0 0 15 0 0 0
4 0 0 0 16 0 0 0
5 0 0 0 17 0 0 0
6 0 0 0 18 0 0 0
7 0 0 0 19 0 0 0
8 0 0 0 20 0 0 0
9 0 0 0 21 0 0 0
10 0 0 0 22 0 0 0
11 0 0 0 23 0 0 0
12 0 0 0 24 0 0 0
NOTE: Tx is to network, Rx is to customer, Disc. is discarded cells
Highlighted Port indicates the ADSL loop is trained.
'N' - Next Page
'?' - System Help Screen
