Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-44 61179641AL4-5B
ATM OAM Settings Menu
ATM OAM Settings
Main Menu \ ATM Circuit Management \ATM OAM Settings\
The ATM OAM Settings menu (see Figure 5-26 ) is used to provision the Total Access 1248
OAM settings and to test the Inband channel PVC for an ATM fed system.
Figure 5-26. ATM OAM Settings Menu
The ATM OAM Settings menu options are shown in Table 5-25 .
Table 5-25. ATM OAM Settings Menu Options
Option Description Function
1 DSLAM OAM Loopback
Location ID This is option is used to enter the loopback location ID
for the Total Access 1248. The remote loopback location
ID is in hexadecimal 16 byte format.
2 DSLAM OAM State This option is used to toggle the Total Access 1248 OAM
state between Disabled and Enabled.
3 Inband OAM Loopback Test This option displays the “Inband OAM Loopback Test
Menu” on page 5-45.
TID: TA1248 Total Access 1248
Unacknowledged Alarms: None
ATM OAM Settings
1. DSLAM OAM Loopback Location ID : FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF
2. DSLAM OAM State : Disabled
3. Inband OAM Loopback Test
Selection :
'?' - System Help Screen
