ADTRAN 1248 - Manual (Page 138)

Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-86 61179641AL4-5B
Self Test Menu
Self Test
Main Menu \ System Management \Self Test\
NOTE
If expansion mode is enabled (refer to “Expansion Menu” on
page 5-90), the Select Shelf menu (see Figure 5-54 ) displays. A host
or client unit must be chosen in order to access the Self Test menu.
Figure 5-54. Select Shelf Menu
The Self Test menu (see Figure 5-55 ) displays ROM, RAM, and EEPROM test results after a
reboot of the Total Access 1248 system. If any tests result in a failed status, the word “
Failed
”
displays next to that test and the PWR LED turns red. An option is provided to test the Total
Access 1248 fans.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
Select Shelf
1. Host
2. Client 1 (configured)
3. Client 2 (configured)
4. Client 3 (configured)
Selection :
'?' - System Help Screen
