ADTRAN 1248 - Manual (Page 131)

Menu Descriptions
61179641AL4-5B 5-79
4. Browse to the file containing the code, select Ymodem for the drop-down menu, and select
S END
.
NOTE
The code begins transmitting from the terminal emulation package.
When the download is complete, the unit restarts automatically.
NOTE
If the download is cancelled due to inactivity, press E SC
to return to
the Code Download Method menu and restart the procedure.
TFTP Download Screen
TFTP Download
Main Menu \ System Management \ Code Download Method \TFTP Download\
The TFTP Download screen (see Figure 5-50 ) is used to download code stored from a computer
to the Total Access 1248 through a TFTP server.
Figure 5-50. TFTP Download Screen
The TFTP Download screen fields are shown in Table 5-49 .
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
TFTP Download
TFTP Server: 10.13.254.20
Get Code For: Host
TFTP Filename:
Error Status:
Update progress:
Press Space bar to enter TFTP address
