Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-28 61179641AL4-5B
OAM Loopback Test Menu
OAM Loopback Test
Main Menu \ ATM Circuit Management \ PVC/PVP Management \ Current ATM OAM Statistics \OAM Loopback Test\
The OAM Loopback Test menu (see Figure 5-16 ) displays the network and line side infor-
mation for each ATM circuit.
Figure 5-16. OAM Loopback Test Menu
The OAM Loopback Test menu options are shown in Table 5-13 .
Table 5-13. OAM Loopback Test Menu Options
Option Description Function
1 Endpoint 1 Remote OAM
Loopback Location ID This option is used to enter the Endpoint 1 remote
loopback location ID. The remote loopback location ID is
in hexadecimal 16 byte format.
2 Endpoint 2 Remote OAM
Loopback Location ID This option is used to enter the Endpoint 2 remote
loopback location ID. The remote loopback location ID is
in hexadecimal 16 byte format.
3 Type of OAM Loopback Cell This option is used to specify the type of OAM Loopback
cell. Options include the following:
• Segment
• End-to-End
TID: TA1248 Total Access 1248
Unacknowledged Alarms: None
OAM Loopback Test
Endpoint 1 Endpoint 2 Modem Status
Port VPI VCI Port VPI VCI Down
0 35 1000 1 0 35
Endpoint 1 (Net --> Cust) Endpoint 2 (Net <-- Cust)
Tx Loopback Request : 0 Tx Loopback Request : 0
Rx Loopback Request : 0 Rx Loopback Request : 0
Tx Loopback Response : 0 Tx Loopback Response : 0
Rx Loopback Response : 0 Rx Loopback Response : 0
Loopback Passed : 0 Loopback Passed : 0
Loopback Failed : 0 Loopback Failed : 0
1. Endpoint 1 Remote OAM Loopback Location ID : FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF
2. Endpoint 2 Remote OAM Loopback Location ID : FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF
3. Type of OAM Loopback Cell : Segment
4. Send from Endpoint 1 to Network
5. Send from Endpoint 2 to Customer
6. Reset Loopback Statistics
Selection :
