Menu Descriptions
61179641AL4-5B 5-127
IMA Link Failure Monitoring Status Screen
IMA Link Failure Monitoring Status
Main Menu \ Network Port \ IMA Main Menu \ Status/Failure Monitoring \IMA Link Failure Monitoring Status\
The IMA Link Failure Monitoring Status screen (see Figure 5-88 ) displays the states for all of
the facilities.
Figure 5-88. IMA Link Failure Monitoring Status Screen
The IMA Link Failure Monitoring Status screen states and failure conditions are shown in
Table 5-90 .
Table 5-90. IMA Link Failure Monitoring Status Screen
States and Failure Conditions
State Definition Failure Condition
Near End Tx States
NotInGr Not In Group, Unassigned This condition indicates that no information about the
link exists.
Deleted Not In Group, Deleted This condition indicates the link has been removed from
the group.
This transitional state ensures that the other end is still
not receiving ATM layer cells before it moves to the
Unassigned state.
Fault Unusable, Fault This condition indicates that a fault has been detected
either on the link or in the link protocol.
No Reas Unusable This condition indicates that a reason was not given.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
IMA Link Failure Monitoring Status
Fac1 Fac2 Fac3 Fac4 Fac5 Fac6 Fac7 Fac8
NE Tx State: Active Active Active Active Active Active Active Active
NE Rx State: Active Active Active Active Active Active Active Active
FE Tx State: Active Active Active Active Active Active Active Active
FE Rx State: Active Active Active Active Active Active Active Active
NE Rx Failure: NoFault NoFault NoFault NoFault NoFault NoFault NoFault NoFault
FE Rx Failure: NoFault NoFault NoFault NoFault NoFault NoFault NoFault NoFault
DiffDelay(ms): >MaxDel >MaxDel >MaxDel >MaxDel >MaxDel >MaxDel >MaxDel >MaxDel
Rx LIF Defect:
Rx LODS Defect:
Rx Link ID: 0 1 2 3 4 5 6 7
Timing Source : Port 1
Last Timing Source Change : MM/DD/YY HH:MM:SS
'?' - System Help Screen
