Page 221
Menu Descriptions
61179641AL4-5B
5-169
ADSL DELT Menus
ADSL DELT Menus
\
\ADSL DELT Menus\
NOTE
If expansion mode is enabled (refer to
page 5-90), the Select Shelf menu (see
) displays. A
host or client unit must be chosen in order to access the
Performance menu.
Figure 5-119. Select Shelf Menu
The ADSL DELT menus (see
) facilitates the selection of a Dual-Ended Loop Test
(DELT). In a DELT diagnostic test, the near-end and far-end modems attain and exchange
information about the quality of the line and connection between the units.
In addition to test configuration information, this menu also provides current test status and
status information on the last test that was run.
NOTE
DELT functionality requires a service mode that supports DELT on
both units.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
Select Shelf
1. Host
2. Client 1 (configured)
3. Client 2 (configured)
4. Client 3 (configured)
Selection :
'?' - System Help Screen
