ADTRAN 1248 - Manual (Page 160)

Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-108 61179641AL4-5B
E1 PM Main Menu
E1 PM Main Menu
Main Menu \ Network Port \ E1 Main Menu \E1 PM Main Menu\
The E1 PM Main Menu (see Figure 5-72 ) is used to access the E1 performance monitoring
displays in 24-hour and 15-minute increments for the current port selected and to clear all E1
performance monitoring data.
Figure 5-72. E1 PM Main Menu
The E1 PM Main Menu options are shown in Table 5-74 .
Table 5-74. E1 PM Main Menu Options
Option Definition Function
1 E1 PM This option displays the “E1 Performance Monitoring
Status Screen” on page 5-109.
2 Clear All E1 PM This option clears E1 performance monitoring data for
all ports.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
E1 PM Main Menu
1. E1 PM
2. Clear All E1 PM
Selection :
'?' - System Help Screen
