Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-124 61179641AL4-5B
Status/Failure Monitoring Menu
Status/Failure Monitoring
Main Menu \ Network Port \ IMA Main Menu \Status/Failure Monitoring\
The Total Access 1248 system tracks Failure Monitoring (FM) for the IMA group and each of
the links. The Status/Failure Monitoring menu (see
Figure 5-86 ) provides two options that
display information about transmitting and receiving states, receiving failure, relative delay,
receiving Loss of IMA Framing (LIF) defect, receiving Link Out of Delay Synchronization
(LODS), receiving defect, and the receiving link identifier for all facilities.
Figure 5-86. Status/Failure Monitoring Menu
The Status/Failure Monitoring menu options are shown in Table 5-88 .
Table 5-88. Status/Failure Monitoring Menu Options
Option Description Function
1 Group FM Status This option displays the “IMA Group 1 Failure
Monitoring Status Screen” on page 5-125.
2 All Links FM Status This option displays the “IMA Link Failure Monitoring
Status Screen” on page 5-127.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
Status / Failure Monitoring
1. Group FM Status
2. All Links FM Status
Selection :
'?' - System Help Screen
