Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-106 61179641AL4-5B
E1 Provisioning Menu
E1 Provisioning
Main Menu \ Network Port \ E1 Main Menu \E1 Provisioning\
The E1 Provisioning screen (see Figure 5-70 ) displays the current E1 settings.
Figure 5-70. E1 Provisioning Menu
The E1 Provisioning menu fields are shown in Table 5-72 .
Table 5-72. E1 Provisioning Menu Options
Option Description Function
1 Framing This field displays the framing setting for the E1 circuit.
Settings include the following:
• FAS+CRC
• FAS
2 Line Code This field displays the line code setting for the E1 circuit.
Settings include the following:
• HDB3
• AMI
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
E1 Provisioning for # 1
1. Framing FAS+CRC
2. Line Code HDB3
'N' - Next E1 Port 'P' - Previous E1 Port
Selection :
'?' - System Help Screen
