Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-98 61179641AL4-5B
T1 Status Menu
T1 Status
Main Menu \ Network Port \ T1 Main Menu \T1 Status\
The T1 Status menu (see Figure 5-64 ) displays the status of the T1 network circuits and a
summary of the associated alarm counts.
Figure 5-64. T1 Status Menu
The T1 Status menu fields are shown in Table 5-65 .
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
T1 Status
1 2 3 4 5 6 7 8
Type DSX DSX DSX DSX DSX FAS FAS FAS
Framing ESF ESF ESF ESF ESF AMI AMI AMI
Line Code B8ZS B8ZS B8ZS B8ZS B8ZS B8ZS B8ZS B8ZS
Line Build Out 0-133 0-133 0-133 0-133 0-133 0-133 0-133 0-133
T1 Alarm RED RED RED RED BLUE RED RED BLUE
Total Alarms
Red 2 2 2 2 0 1 1 0
Yellow 0 0 0 0 0 0 0 0
Blue 0 0 0 0 1 0 0 1
10. Reset Alarm Counts Cleared: 01/15/94 05:19:17
Selection :
'?' - System Help Screen
