ADTRAN 1248 - Manual (Page 152)

Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-100 61179641AL4-5B
T1 PM Main Menu
T1 PM
Main Menu \ Network Port \ T1 Main Menu \T1 PM\
The T1 PM Main Menu (see Figure 5-65 ) is used to access the T1 performance monitoring
displays in 24-hour and 15-minute increments for the current port selected and to clear all T1
performance monitoring data.
Figure 5-65. T1 PM Main Menu
The T1 PM Main Menu options are shown in Table 5-66 .
Table 5-66. T1 PM Main Menu Options
Option Definition Function
1 T1 PM This option displays the “T1 Performance Monitoring
Status Screen” on page 5-101.
2 Clear All T1 PM This option clears T1 performance monitoring data for
all ports.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
T1 PM Main Menu
1. T1 PM
2. Clear All T1 PM
Selection :
'?' - System Help Screen
