Menu Descriptions
61179641AL4-5B 5-163
ATU-R Information
ATU-R Information
Main Menu \ DSL Menus \ Status \ATU-R Information\
The ATU-R Information screen (see Figure 5-112 ) provides information for the remote end of
the circuit. If the line is trained up in T1.413 mode, the screen shows a Vendor ID for the
customer’s modem, and the The Provider Code is blank. If the line is trained up in G.dmt
mode, the Vendor ID is blank and the Provider Code for the customer’s modem is shown. Note
that this line is trained up in T1.413 mode. The next or previous port can be selected by using
the
N or P hot keys.
Figure 5-112. ATU-R Information Screen
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
Shelf = Host
Line 17 ATU-R Information
Link Status Up T1.413
Vendor ID 34
Provider Code N/A
Version Number 1
ADSL Capabilities N/A
S - Select Port N - Next Port P - Previous Port
Current Port: 17
'?' - System Help Screen
