Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-150
61179641AL4-5B
Service Mode for Port: # Menu
Service Mode for Port: #
\
\
\
\Service Mode for Port: #\
The Service Mode option on the
displays the Service Mode for Port: #
menu. The # represents the value displayed for the Select Port option. The service mode refers
to the data mode for the traffic between the DSLAM and the modem.
The Service Mode for Port: # menu options are shown in
.
If a mode is specified, it must be one supported by the customer’s modem.
Hamband Mask for Port: # Menu
Hamband Mask for Port: #
\
\
\
\Hamband Mask for Port: #\
The Hamband Mask option on the
displays the Hamband Mask for
Port: # menu. The # represents the value displayed for the Select Port option. Hamband Mask
is for masking out frequencies that are used by hamband (ham radios) so that those
frequencies and their respective tones do not interrupt the training process.
The Hamband Mask for Port: # menu options are shown in
.
Table 5-105. Service Mode for Port: # Menu Options
Option
Description
Function
1
Multimode
Multimode allows the DSLAM and the modem to pick a
mode for the line to use to train up.
2
T1.413
This option sets T1.413 as the Service Mode.
3
G.dmt
This option sets G.dmt as the Service Mode.
4
G.lite
This option sets G.lite as the Service Mode. If the mode
is set to G.lite, the Line Type should be set to Interleave
from the
on page 5-140 for these
ports. Even if the Line Type remains set to Fast, the
modem can only train up as Interleave.
5
ADSL2
This option sets ADSL2 as the Service Mode.
6
ADSL2.lite
This option sets ADSL2.lite as the Service Mode.
7
ADSL2+
This option sets ADSL2+ as the Service Mode.
8
READSL
This option sets READSL as the Service Mode.
9
Legacy Multimode (ADSL1)
This option sets Legacy Multimode as the Service Mode.
