SNMP/TFTP and TL1 Configuration Storage and Retrieval
61179641AL4-5B 6-3
SNMP/TFTP AND TL1 CONFIGURATION STORAGE AND RETRIEVAL
Use the following SNMP/TFTP and TL1 commands to store or retrieve the Total Access 1248
System Configuration Archive (SCA) file.
NOTE
In some installations, the configuration file can be stored and
retrieved in one operation for multiple Total Access 1248 systems.
This is accomplished by incorporating the SNMP/TFTP or TL1 com-
mands into scripts.
SNMP / TFTP
These objects are located in the ADTRAN-TA1200Shelf-MIB.mib, under adTA1200ShelfProv.
Save
Set TFTP Server IP address with adTA1200SCATftpServerHostName
Set filename using adTA1200SCAFileName
Initiate transfer using adTA1200SCAInitiateSave (option initiate (1))
Restore
Set TFTP Server IP address with adTA1200SCATftpServerHostName
Set filename using adTA1200SCAFileName
Initiate transfer using adTA1200SCAInitiateRestore (option initiate (1))
