Menu Descriptions
61179641AL4-5B 5-31
Current ATM PVC Performance Menu
Current ATM PVC Performance
Main Menu \ ATM Circuit Management \ PVC/PVP Management \Current ATM PVC Performance\
The Current ATM PVC Performance menu (see Figure 5-17 ) displays the network and port side
information for each ATM circuit.
Figure 5-17. Current ATM PVC Performance Menu
The Current ATM PVC Performance menu options are shown in Table 5-15 .
Table 5-15. Current ATM PVC Performance Menu Options
Option Description Function
1 Clear Current PVC PM This option clears the currently displayed PVC
performance monitoring statistics.
2 Clear All PVC PM This option clears all the PVCs performance monitoring
statistics.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
Current ATM PVC Performance
Endpoint 1 Endpoint 2 Modem Status
Port VPI VCI Port VPI VCI Down
0 35 1000 1 0 35
Endpoint 1 (Net --> Cust) Endpoint 2 (Net <-- Cust)
Tx Cells : 0 Tx Cells : 0
Discarded Queue Full : 0 Discarded Queue Full : 0
Cells/Sec (Last Sec) : 0 Cells/Sec (Last Sec) : 0
Cells/Sec (60 Sec Avg): 0 Cells/Sec (60 Sec Avg): 0
1. Clear Current PVC PM
2. Clear All PVC PM
Selection :
'N' - Next PVC 'P' - Previous PVC 'S' - Select PVC
'?' - System Help Screen
