Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-60 61179641AL4-5B
Static IP Settings - for IP over Ethernet Menu
Static IP Settings - for IP over Ethernet
Main Menu \ System Management \ Mode Selection and Current IP Settings \Static IP Settings - for IP over Ethernet\
The Static IP Settings - for IP over Ethernet menu (see Figure 5-36 ) is used to manually
provision all of the IP settings.
Figure 5-36. Static IP Settings - for IP over Ethernet Menu
The Static IP Settings - for IP over Ethernet menu options are shown in Table 5-36 .
TID: TA1248 Total Access 1248
Unacknowledged Alarms: None
Static IP Settings - for IP over Ethernet
1. IP address 192.168.1.1
2. Subnet mask 255.255.255.0
3. Default Gateway 192.168.1.254
4. TFTP IP address Not Configured
5. TL1 Port Number(set >1023) 13001
6. TL1 IP Transport type TCP
7. Reset IP Factory Defaults
MAC Address 00-a0-c8-12-6d-f9
Selection :
'?' - System Help Screen
