Total Access 1248 Octal T1 IMA DSLAM with Modem Installation and Maintenance Practice
5-58
61179641AL4-5B
NOTE
The Media Access Control (MAC) address is set at the factory.
Table 5-34. Dynamic IP Settings - for IP over ATM Menu Items
Option
Description
Function
N/A
IP address
This option cannot be changed. The IP address is
automatically retrieved from the DHCP server.
N/A
Subnet mask
This option cannot be changed. The Subnet mask is
automatically retrieved from the DHCP server.
3
VPI/VCI
This option is used to configure the VPI/VCI setting. The
VPI and VCI are used to identify the next destination of a
cell as it passes through a series of ATM switches.
The VPI/VCI must also be provisioned at the upstream
ATM device.
4
PCR
This option is used to configure the Peak Cell Rate
(PCR). The PCR is the maximum number of cells per
second that the ATM can transmit. The PCR default is
3000. Valid values range from 0 to 14488.
N/A
Default Gateway
This option cannot be changed. The Default Gateway is
automatically retrieved from the DHCP server.
6
TFTP IP address
This option is used to configure the TFTP IP address.
The TFTP IP Address must be configured to use TFTP for
software upgrade. The TFTP address is configured in
decimal dot format.
7
TL1 Port Number (set >1023)
This field is used to configure the Transaction Language
1 Port Number. The default TL1 Port Number is 13001,
however, it can be modified to any number greater than
1023.
8
TL1 IP Transport type
This option is used to configure the TL1 IP Transport
Type. Each time the TL1 IP Transport type option is
selected, the setting is toggled between User Datagram
Protocol (UDP) and Transmission Control Protocol (TCP).
The default is TCP.
9
Reset IP Factory Defaults
This option displays the
