- 150 -

29.3. Barcode scanner

The balance enables cooperating with barcode scanners, which are used to

quick searching for a product in the database of products. Connection to a
barcode scanner is configured in submenu < Barcode Scanner>.

Available options:

Setting communication port with a barcode scanner,

Offset setting,

Setting barcode length.

Caution:

Submenu <

Communication> requires setting baud rate to compatible with the

one used barcode scanner (default 9600b/s). Detailed description of communicating

the balance with a barcode scanner is provided in APPENDIX F of this user manual.

The balance enables communicating with a barcode scanner using the

following ports:

RS 232 (COM1),

RS 232 (COM2),

Offset

Setting the first data carrying character of a barcode, which is the first

recognized character while searching for a product.

Code length

Setting number of characters recognized during searching for a product.

29.4. Transponder card reader

Selecting (logging) a user on each switching on the balance can be carried out

by means of:

Inserting user’s password using on-screen keyboard,

With a transponder card scanner, by approximating a registered card to the

scanner.

Caution:

For correct balance’s cooperation with a transponder card reader set appropriate baud
rate value in submenu <

Communication> (default 9600b/s).

Transponder card scanner port.

The balance enables communicating with a transponder card scanner using

the following ports:

RS 232 (COM1),

RS 232 (COM2).

Assigning number of a card to a user:

In order to log in an operator using a transponder card scanner, first assign a

number of an already registered card to a selected user in the database of

operators.
