- 143 -

28. COMMUNICATION

Menu Communication is located in a menu group Parameters. It is accessed
by pressing Setup key or <

Setup > quick access key. The balance enables

communicating with peripheral devices through the following ports:

COM 1 (RS232),

COM 2 (RS232),

Ethernet,

Tcp.

The ports are configured in group of parameters <

Communication>.

Enter submenu <

Communication> by pressing

key, and press “

Communication” filed.

28.1. RS 232 port settings

Procedure:

Select communication port <

COM1> or <

COM2>,

Set appropriate values

The RS 232 ports enable the following setting of transmission parameters:

Baud rate - 4800, 9600, 19200, 38400, 57600, 115200 bit/s

Data bits - 5, 6, 7, 8

Stop bits - None, 1, 1.5, 2

Parity - None, Odd, Even, Marker, Interval

28.2. ETHERNET port settings

Procedure:

Select communication port <

Ethernet> and set appropriate values:

DHCP - Yes – No

IP Address - 192.168.0.2

Subnet mask - 255.255.255.0

Default gate - 192.168.0.1

Caution:

Above settings are for information purpose only. Transmission parameters should be

selected in accordance with the settings of client’s local network.


To carry out changes in the settings, press

key which displays a message:

,

Return to weighing mode and restart the device.

28.3. WiFi settings

For balance equipped with WiFi module the top toolbar of the main display has

a respective WiFi icon:
