RADWAG MYA 5.3Y.F1 Microbalance User Manual
Page 137
- 137 -
•
In the
•
A window is opened for creating an optional printout
•
While designing a printout use on-screen keyboard displayed on the touch
panel. It features the same options as a regular computer keyboard.
1 – enlarging the editing field (7), recommended while using an external
computer keyboard connected to balance’s USB port
2 – cancelling key
3 – accepting key
4 – download a printout template from a file
5 – list of variables for use while designing a printout
6 – delete all printout content
7 – printout editing field
•
Save designed printout
Caution:
To erase characters in a printout press Back key. To move cursor press navigating
arrows.
Example of Printout no. 1 – use of large editing field
Balance no. 400015
Balance parameters:
Max = 220 g
d= 0.001 g
Product name:
Date: 2011.10.24
Time: 11:48:06
------------------------
Working mode: Weighing
------------------------
