AT-S25 Version 1.4 User’s Guide
85
5. Return to the Main Menu.
Displaying the
Port Number of a
MAC Address
The Omega interface allows you to determine the port on which a MAC
address is located by specifying the address. This feature is useful in
determining the port that a particular device is connected to on a switch.
To display the port number for a specific MAC address, perform the
following procedure:
1. From the Main Menu, select the switch where you believe the device
is connected.
2. From the Main Menu, select MAC Address Table.
3. Select Get Port From MAC Address.
The MAC Address prompt shown in Figure 38 is displayed.
Figure 38 MAC Address Prompt
4. Enter the source MAC address. Press or select Enter.
The MAC address should be entered in the following format:
XXXXXX XXXXXX
The screen displays a window that contains the port on which the
MAC address was learned. Figure 39 is an example of the window.
Figure 39 MAC Addresses Located on a Port Window
5. Return to the Main Menu.
