AT-S25 Version 1.4 User’s Guide
107
Activating or Deactivating the Basic VLAN Mode
This section contains the procedure for activating or deactivating the
Basic VLAN Mode.
Note
For information on the Basic VLAN Mode, refer to Basic VLAN Mode
on page 152 in Appendix A, Introduction to Virtual LANs.
To activate or deactivate the Basic VLAN Mode, perform the following
procedure:
1. From the Main Menu, select any switch in the stack.
2. From the Main Menu, select System Configuration.
The System Configuration menu is displayed, as shown in Figure
7 on page 39.
3. Select Switch-mode Selection.
4. The Switch Mode window shown in Figure 51 is displayed.
Figure 51 Switch Mode Window
5. To activate the Basic Switch Mode, select Basic Mode from the
window. To deactivate Basic Switch Mode and so be able to create
and modify port-based and tagged VLANs, select Tag Mode (default
mode) from the window.
6. Return to the Main Menu.
7. It is recommended that you reset the stack after either activating or
deactivating the Basic VLAN Mode. For instructions, refer to
Resetting a Stack on page 51 in Chapter 2.
