Supported Platforms
160
AT-A18 4 10/100Base-TX RJ-45 100 m (328 ft)
AT-A19 2 100Base-FX MT-RJ 2 km (1.25 mi)
AT-A22/SX 1 1000Base-SX SC 550 m (1,804 ft)
AT-A22/LX 1 1000Base-LX SC 10 km (6.2 mi)
AT-A24/SX 1 1000Base-SX MT-RJ 550 m (1,804 ft)
AT-A24/LX 1 1000Base-LX MT-RJ 10 km (6.2 mi)
1. The maximum distance may be less depending on the duplex mode of the end nodes and the type of cabling used with the module.
Table 9 Optional Expansion Modules
Model
Number
of Ports
Type of Ports
Type of
Connector
Maximum Distance
1
