Allied Telesis AT-S25 - Manual (Page 106)

106
Deleting a VLAN
To delete a VLAN from a stack, perform the following procedure:
1. From the Main Menu, select any switch in the stack.
It does not matter which switch in a stack you select when
deleting a VLAN.
2. From the Main Menu, select Virtual LANs/QoS.
The Virtual LAN/QoS menu in Figure 48 on page 98 is displayed.
3. Select Virtual LAN definitions.
The VLANs window in Figure 49 on page 99 is displayed.
4. Select the name of the VLAN to be deleted.
Note
You cannot delete the Default VLAN.
The current configuration for the selected VLAN is displayed. An
example is shown in Figure 50 on page 100.
5. Select the VLAN Name field and enter an asterisk (*) in the field. Press
.
6. Select Update this Vlan.
The VLAN is now deleted from the stack. All ports in the VLAN are
returned to the Default VLAN.
7. Return to the Main Menu.
