The table below lists the ports assignments for the Sales and Production
VLANs:
Each VLAN is briefly summarized below:
❑ Sales VLAN
— This VLAN has been assigned a VID of 2 and the
ports, correspondingly, have been automatically assigned a PVID
also of 2. This VLAN spans both the AT-8300 Series stack and the
AT-8224XL Switch. Ports 1 to 6 on the master AT-8324 Switch and
ports 1 to 4 on the slave switch are connected to workstations and
a server. Port 7 on the master switch is connected to the router,
which allows the Sales VLAN to communicate with the Production
VLAN and also to the WAN. Port 8 on the slave switch is
functioning as a direct link to the second part of the Sales VLAN,
located on the AT-8224XL Switch.
❑ Production VLAN
— This VLAN has been assigned a VID of 3 and
the ports a PVID of 3. Ports 19 to 24 on the master AT-8324 Switch
and ports 21, 23, and 24 on the slave switch are connected to
workstations. Port 17 on the master switch is connected to a
router for interconnection to the Sales VLAN and the WAN, and
port 20 on the slave switch is connected to the AT-8224XL Switch
to interconnect the two parts of the Production VLAN.
Table 8-1 Port Assignments of the Port-based VLAN Example
Sales VLAN
(VID 2) Production VLAN
(VID 3)
AT-8300 Series Stack
AT-8324 Switch (master) Ports 1 - 7 (PVID 2) Ports 17, 19 - 24 (PVID 3)
AT-8324 Switch (slave) Ports 1 - 4, 8 (PVID 2) Ports 20, 21, 23, 24 (PVID 3)
AT-8224XL Switch Ports 1 - 4, 7 (PVID 2) Ports 19, 21 -2 4 (PVID 3)
